2009 Chevrolet C6500 Box Truck 13’6: Ultimate Guide

Thomas William

May 29, 2025

2009 Chevrolet C6500 Box Truck 13’6

If you’re hunting for a dependable medium-duty truck that delivers power, payload, and proven durability, the 2009 Chevrolet C6500 Box Truck 13’6 might just be your best-kept secret. Despite being over a decade old, this workhorse still finds a home in countless delivery fleets, contractor businesses, and moving companies.

But why does this aging juggernaut still get the nod over newer, shinier options? And what does “13’6” actually mean? This ultimate guide unpacks everything—technical specs, real-world applications, ownership costs, and buyer advice.

Overview of the 2009 Chevrolet C6500 Box Truck 13’6

Part of Chevrolet’s TopKick series, the C6500 is a Class 6 medium-duty truck built on a strong chassis. It was manufactured in collaboration with General Motors and Isuzu to serve a variety of commercial needs—from box delivery trucks to utility rigs.

This particular model often comes equipped with a Duramax diesel engine, a robust Allison transmission, and a box cargo body, making it an ideal solution for businesses that need both strength and versatility.

What Does 13’6 Mean on the Box Truck?

The term “13’6” refers to the height of the truck, including the box. In most states and federal transportation guidelines, the maximum legal height for commercial vehicles is 13 feet, 6 inches. This makes the C6500 compliant with most bridge and overpass clearances, particularly on highways and major roads.

However, caution is needed when operating on rural roads or under low-hanging utility lines.

Technical Specifications Breakdown

  • Engine: 6.6L Duramax Turbo Diesel V8

  • Horsepower: ~300 HP

  • Torque: 520–605 lb-ft

  • Transmission: Allison 5-speed automatic or 6-speed manual

  • Fuel Type: Diesel

  • Drivetrain: Rear-wheel drive or available dual rear-wheel

  • GVWR: Up to 25,950 lbs (no CDL required)

Box Dimensions and Cargo Capacity

The box attached to this truck often measures 24 to 26 feet in length, with a height of 13’6. It typically provides around 1,500 to 1,800 cubic feet of cargo space, depending on configuration.

Payload capacity varies by model and specs, but can range between 9,000 to 11,500 lbs, making it ideal for furniture movers, appliance delivery, and palletized freight.

Who Is the 2009 Chevrolet C6500 For?

This truck is purpose-built for:

  • Moving and relocation companies

  • Last-mile delivery businesses

  • Industrial service contractors

  • HVAC and plumbing service fleets

  • Food and beverage distributors

Why Businesses Still Buy This 2009 Model Today

Here’s the kicker: durability. The 2009 C6500 is known for:

  • Reliable drivetrain longevity

  • Lower ownership costs

  • Simpler electronics vs newer trucks

  • Parts availability due to GM’s support

  • Strong aftermarket and mechanic familiarity

It’s a favorite for buyers looking to avoid the complexity (and cost) of newer emissions systems and telematics.

Under the Hood: Powertrain Details

The Duramax 6600 V8 engine remains a legend in the medium-duty world. It delivers:

  • Better fuel burn efficiency

  • Quieter operation than older diesel engines

  • Consistent torque for hill climbs and towing

  • Minimal turbo lag

Routine maintenance keeps these engines running well past 250,000 miles.

Transmission and Driving Experience

The Allison 2500 or 3000 series transmission is known for:

  • Smooth gear transitions

  • Low maintenance intervals

  • Torque converter lock-up for improved fuel economy

Drivers find it responsive, especially when hauling near max GVWR.

Suspension System and Ride Comfort

The front typically includes taper-leaf or parabolic springs, while the rear has multi-leaf or air suspension setups.

  • Air suspension is smoother for fragile goods

  • Leaf springs are rugged for rough terrains

The cab is basic, but functional—great visibility, straightforward controls, and decent seat cushioning.

Fuel Economy and Operating Costs

Expect 6 to 9 miles per gallon, depending on:

  • Load weight

  • Traffic conditions

  • Terrain

  • Driving behavior

With a 50-gallon fuel tank, range estimates are around 300–400 miles per fill.

Towing and Payload Ratings

  • GVWR: Up to 25,950 lbs

  • GCWR: Approximately 33,000 lbs

  • Towing Capacity: Up to 10,000 lbs (with proper hitching)

These numbers make it viable for trailers, flatbeds, and even mobile equipment transport.

Chassis and Frame Durability

Built on a ladder-style frame, the C6500 features:

  • Steel reinforcement

  • Rust-resistant coatings

  • Tight riveted joints

It can handle extreme weather and heavy commercial workloads with minimal frame fatigue.

Interior Cabin Features and Ergonomics

  • Bench or bucket seating

  • Manual HVAC or optional A/C

  • AM/FM stereo (basic models)

  • Cup holders and overhead storage

The dash layout is straightforward—designed for practicality, not luxury.

Safety Features in the 2009 C6500 Box Truck

While it predates modern digital ADAS systems, it includes:

  • 4-wheel anti-lock braking system (ABS)

  • Manual and power steering options

  • Dual airbag setup

  • Large mirrors and optional rearview camera kits

Tire Specifications and Maintenance Tips

Most C6500s ride on 22.5-inch commercial-grade wheels. Common tire sizes include:

  • Front: 275/70R22.5

  • Rear: 295/75R22.5 (dual-wheel)

Recommended PSI: 95–105 lbs, depending on load. Rotate every 6,000–8,000 miles and align bi-annually.

Turning Radius and Maneuverability

The turning radius of the 2009 C6500 ranges from 35 to 50 feet, depending on wheelbase. While it’s not nimble like a van, it performs well in commercial depots and industrial parks.

Licensing and CDL Requirements

Most C6500 configurations fall just below 26,000 lbs GVWR, meaning:

  • No CDL required in most U.S. states

  • Still classified as a commercial vehicle, requiring DOT compliance

Used Market Price Trends in 2025

As of 2025, pricing depends on mileage and condition:

Condition Price Estimate
Excellent (under 100K miles) $25,000–$32,000
Good (150K miles) $18,000–$24,000
Fair (200K+ miles) $12,000–$17,000

Where to Buy or Sell the 2009 Chevrolet C6500

  • TruckPaper.com

  • CommercialTruckTrader

  • Facebook Marketplace

  • Local Auctions and Dealer Lots

Tip: Always request maintenance logs and perform a third-party inspection.

Insurance Considerations and Costs

Commercial box trucks typically cost $2,500–$4,000 annually to insure, based on:

  • Location

  • Driver record

  • Business use

  • Coverage amount

Shop around for fleet discounts or use brokers specializing in medium-duty trucks.

Maintenance Schedule Guide

Task Frequency
Oil & Filter Change Every 7,500 miles
Fuel Filter Every 15,000 miles
Transmission Fluid Every 30,000 miles
Brake Inspection Every 10,000 miles
Air Filter Every 20,000 miles
Coolant Flush Every 60,000 miles

Stick to this, and your truck may hit the 500,000-mile mark with ease.

Common Issues and How to Fix Them

  • Glow plug failures: replace in pairs

  • Brake rotor wear: resurface or replace

  • Fuel system clogging: use quality diesel additives

  • Electrical gremlins: inspect fuse box and wiring harness

Pros and Cons of the 2009 Chevy C6500

Pros:

  • Strong powertrain

  • No-nonsense design

  • Easy maintenance

  • Excellent payload capacity

Cons:

  • Noisy under load

  • Basic interiors

  • Lacks modern driver aids

Comparing 2009 C6500 to Modern Box Trucks

Modern trucks offer:

  • Digital dashboards

  • Hybrid or electric variants

  • GPS integration

  • Advanced safety features

But they come at 2x or 3x the price. The 2009 C6500 remains a budget-conscious powerhouse.

Aftermarket Parts and Customizations

Popular upgrades include:

  • Liftgates for easier loading

  • E-track systems inside the box

  • Backup cameras

  • LED lighting

  • In-dash GPS systems

Best Practices for Loading and Cargo Securing

  • Distribute weight evenly

  • Use ratchet straps and cargo bars

  • Load heavy items on the floor

  • Avoid exceeding axle weight ratings

Safety first—for you and your cargo.

Real-World Owner Reviews and Testimonials

“We’ve used our 2009 C6500 for 7 years hauling commercial HVAC systems. It’s ugly, it’s loud, but it’s a beast.”Tony G., HVAC contractor, Ohio

“Bought used with 170,000 miles. Now pushing 300,000. Just oil, filters, and brakes—solid truck.”Maria L., Independent Mover, Texas

Conclusion

If you’re in the market for a durable, high-capacity box truck, the 2009 Chevrolet C6500 13’6 deserves serious consideration. It’s built like a tank, easy to maintain, and offers incredible value in the used commercial vehicle market.

Yes, it lacks the fancy tech. But if your business is about muscle over bells and whistles, this truck may be the ultimate fleet addition.
